Hydraulic Motors for Sale in South Africa
Hydraulic Motor Suppliers for Earthmoving, Mining, Construction & Industrial Equipment
Nkokhi Group (Pty) Ltd supplies hydraulic motors in South Africa for earthmoving machinery, mining equipment, construction machinery, agricultural equipment, industrial systems, material-handling equipment and other hydraulic applications.
We source and supply hydraulic motors, hydraulic drive motors, orbital motors, piston motors, radial piston motors, axial piston motors, wheel motors, gear motors and replacement hydraulic motors for a wide range of machines and hydraulic systems.
Whether you require a hydraulic motor replacement, OEM-equivalent motor, complete drive motor or a motor matched to an existing hydraulic system, our team can assist with identifying the correct specification.
Request a hydraulic motor quotation from Nkokhi Group today.
Hydraulic Motors for Sale
A hydraulic motor converts hydraulic energy into rotational mechanical energy. Pressurised hydraulic oil enters the motor and produces rotation at the output shaft. Motor torque is influenced by hydraulic pressure and displacement, while speed is primarily related to hydraulic flow and motor displacement.
Nkokhi Group supplies hydraulic motors for applications including:
- Earthmoving machinery
- Mining equipment
- Excavators
- Wheel loaders
- Bulldozers
- Motor graders
- Road construction equipment
- Drilling equipment
- Crushing and screening equipment
- Conveyor systems
- Winches
- Cranes
- Sweepers
- Augers
- Mixers
- Fans and cooling systems
- Agricultural machinery
- Forestry equipment
- Industrial machinery
- Marine equipment
- Material-handling equipment
Hydraulic Motor Types
Choosing the correct hydraulic motor depends on the required torque, speed, displacement, pressure, flow, duty cycle, mounting configuration and application.
1. Orbital Hydraulic Motors
Orbital hydraulic motors, also known as gerotor, geroler or low-speed high-torque (LSHT) motors, are widely used where compact size and substantial torque are required.
Typical applications include:
- Conveyors
- Augers
- Sweepers
- Agricultural equipment
- Reels
- Small winches
- Fans
- Mobile machinery
Orbital motors are available in a wide range of displacements and mounting configurations.
Popular Orbital Motor Series
Examples of commonly encountered orbital motor families include:
- Danfoss OMS
- Danfoss OMR
- Danfoss OMP
- Danfoss OMT
- Danfoss OMV
- Eaton Char-Lynn orbital motors
- M+S Hydraulic orbital motors
- White Drive Products motors
- Parker orbital motors
The exact replacement must be selected according to displacement, shaft, mounting, ports, speed, pressure and application.
2. Hydraulic Gear Motors
Hydraulic gear motors use pressurised hydraulic fluid to rotate gears and generate mechanical output.
They are often selected for applications where simplicity, durability and cost effectiveness are important.
Typical applications include:
- Cooling fans
- Conveyors
- Agricultural equipment
- Sweepers
- Material handling
- Auxiliary drives
- Industrial machinery
Common Hydraulic Gear Motor Manufacturers
- Parker
- Eaton
- Bosch Rexroth
- Bucher Hydraulics
- Danfoss
- Casappa
- Marzocchi
- Permco
- Commercial Intertech
3. Axial Piston Hydraulic Motors
Axial piston motors are widely used for demanding hydraulic drive applications. They can be configured as fixed-displacement or variable-displacement motors, with swashplate and bent-axis designs available.
Applications include:
- Excavator drives
- Hydrostatic transmissions
- Wheel drives
- Track drives
- Mining equipment
- Construction equipment
- Industrial hydraulic systems
- Winches
- High-pressure hydraulic applications
Popular Axial Piston Motor Series
Examples include:
- Bosch Rexroth A2FM
- Bosch Rexroth A2FE
- Bosch Rexroth A4FM
- Bosch Rexroth A6VM
- Bosch Rexroth A10VM
- Danfoss 90 Series
- Danfoss 51 Series
- Danfoss 51V Series
- Parker F11
- Parker F12
- Eaton 6K Series
- Eaton 54 Series
Model availability and specifications vary by manufacturer and configuration.
4. Radial Piston Hydraulic Motors
Radial piston motors are designed for applications requiring high torque, particularly at low rotational speeds. They are used in demanding industrial, mining, marine and mobile applications.
Typical applications include:
- Heavy-duty winches
- Mining machinery
- Drilling equipment
- Marine drives
- Crushers
- Conveyors
- Rotary drives
- Heavy-duty industrial equipment
Radial Piston Motor Manufacturers
Nkokhi Group can source radial piston motors from leading manufacturers and specialist hydraulic suppliers, including:
- Bosch Rexroth
- Hägglunds
- Kawasaki
- Poclain
- Eaton
- SAI
- Italgroup
- Parker
- Danfoss
5. Bent-Axis Hydraulic Motors
Bent-axis piston motors are designed for high-pressure and high-speed applications and are available in fixed and variable displacement configurations.
They are commonly used in:
- Hydrostatic drives
- Mobile machinery
- Wheel drives
- Industrial drives
- Construction equipment
- Heavy-duty hydraulic systems
Bent-axis motors are particularly useful where efficiency, high power density and high-speed operation are required.
6. Hydraulic Wheel Motors
Hydraulic wheel motors provide direct hydraulic drive to wheels and are commonly used on mobile machinery.
Applications include:
- Wheel loaders
- Sweepers
- Agricultural machinery
- Utility vehicles
- Compact construction machinery
- Mining equipment
- Specialist mobile equipment
Nkokhi Group can source complete wheel motor assemblies as well as replacement hydraulic motors, depending on machine and application.
Hydraulic Motors for Earthmoving Machinery
Nkokhi Group supplies hydraulic motors for a wide range of yellow plant and earthmoving equipment.
Excavator Hydraulic Motors
We can source hydraulic motors for:
- Excavator travel drives
- Swing drives
- Fan drives
- Auxiliary hydraulic systems
- Final-drive assemblies
Wheel Loader Hydraulic Motors
Hydraulic motors may be used for:
- Cooling fans
- Auxiliary hydraulic systems
- Hydrostatic drive systems
- Wheel-drive systems
- Attachments
Dozer Hydraulic Motors
Applications may include:
- Fan drives
- Hydraulic attachments
- Auxiliary drives
- Hydrostatic systems
Motor Grader Hydraulic Motors
We can assist with sourcing motors for:
- Hydraulic fan systems
- Auxiliary systems
- Steering-related hydraulic applications
- Attachments and implements
Hydraulic Motor Models & Series
The following are examples of hydraulic motor model families that Nkokhi Group can source or identify.
| Manufacturer | Hydraulic Motor Models / Series |
|---|---|
| Bosch Rexroth | A2FM, A2FE, A4FM, A6VM, A10VM |
| Danfoss | OMS, OMR, OMP, OMT, OMV, 51 Series, 90 Series |
| Eaton | Char-Lynn, 6K, 54 Series |
| Parker | F11, F12, TE, TG, TF, TB, TA |
| Hägglunds | Compact, CB, CA, MB, MA |
| Poclain Hydraulics | MS, MI, MK, MR, MCR |
| Kawasaki | Staffa radial piston motor ranges |
| M+S Hydraulic | MS, MR, ML, MP, MV and orbital motor ranges |
| SAI | GM, SM and radial piston motor ranges |
| Italgroup | Radial piston and hydraulic motor ranges |
| Linde | Hydraulic drive motor ranges |
| Kawasaki / Kayaba | Hydraulic motor and drive solutions |
Important: Model codes can have multiple variants. Always provide the complete motor model/code and nameplate information when requesting a replacement.
Hydraulic Motors for Popular Equipment Brands
Nkokhi Group can assist with hydraulic motor sourcing for machinery from manufacturers including:
Caterpillar Hydraulic Motors
- CAT Excavators
- CAT Wheel Loaders
- CAT Dozers
- CAT Motor Graders
- CAT Compact Equipment
- CAT Mining Equipment
Komatsu Hydraulic Motors
- Komatsu Excavators
- Komatsu Wheel Loaders
- Komatsu Dozers
- Komatsu Mining Equipment
- Komatsu Construction Equipment
Volvo Hydraulic Motors
- Volvo Excavators
- Volvo Wheel Loaders
- Volvo Articulated Haulers
- Volvo Construction Equipment
Hitachi Hydraulic Motors
- Hitachi Excavators
- Hitachi Mining Equipment
- Hitachi Construction Equipment
Bell Equipment Hydraulic Motors
- Bell Articulated Dump Trucks
- Bell Wheel Loaders
- Bell Earthmoving Equipment
Other Equipment
We also source hydraulic motors for equipment manufactured by:
- JCB
- Liebherr
- Hyundai
- Doosan
- Kobelco
- CASE
- John Deere
- Manitou
- SANY
- XCMG
- LiuGong
- SEM
- SDLG
- Develon
Hydraulic Motor Manufacturers
Nkokhi Group can source hydraulic motors from major international manufacturers and aftermarket suppliers.
Bosch Rexroth
Bosch Rexroth manufactures axial piston, radial piston and low-speed high-torque hydraulic motor solutions for mobile and industrial applications.
Danfoss
Danfoss hydraulic motor ranges include orbital motors and high-performance piston motor solutions used in mobile and industrial hydraulic systems.
Parker Hannifin
Parker manufactures hydraulic motor solutions covering gear, piston, vane and orbital applications.
Eaton
Eaton hydraulic motors include Char-Lynn orbital motors and other hydraulic drive solutions.
Hägglunds
Hägglunds radial piston motors are used in high-torque, low-speed applications including heavy industrial and mobile machinery.
Kawasaki
Kawasaki hydraulic motor technology includes high-performance piston and radial piston motor solutions.
Poclain Hydraulics
Poclain specialises in hydraulic motors and hydrostatic drive systems for mobile machinery and heavy-duty applications.
M+S Hydraulic
M+S Hydraulic manufactures orbital and other hydraulic motor ranges for mobile and industrial applications.
Nkokhi Group can also source OEM, replacement, aftermarket and equivalent hydraulic motors, subject to availability and application requirements.
Hydraulic Motor Replacement
If your hydraulic motor has failed, replacing it with a motor that simply fits physically may not be sufficient.
The replacement motor should be checked against:
- Original manufacturer
- Complete part number
- Model number
- Displacement
- Maximum pressure
- Continuous pressure
- Maximum speed
- Required flow
- Shaft type
- Shaft diameter
- Shaft length
- Mounting flange
- Bolt-hole pattern
- Port size
- Port configuration
- Rotation
- Case-drain requirements
- Brake configuration
- Sensor configuration
- Gearbox or planetary reduction
- Machine application
A correct hydraulic motor match helps prevent premature failure and hydraulic-system performance problems.
Hydraulic Motor Selection Guide
Before purchasing a hydraulic motor, determine the following:
1. Required Torque
Determine the torque required to drive the equipment.
2. Operating Speed
Establish the required RPM, including minimum, normal and maximum operating speed.
3. Hydraulic Flow
Available hydraulic flow affects motor speed.
4. Hydraulic Pressure
Check both normal operating pressure and peak pressure.
5. Motor Displacement
Displacement is normally specified in cc/rev or similar units.
6. Mounting
Check the flange, bolt pattern, pilot diameter and mounting orientation.
7. Shaft
Confirm:
- Splined shaft
- Keyed shaft
- Tapered shaft
- SAE shaft
- DIN shaft
- Shaft diameter
- Shaft length
8. Hydraulic Ports
Check port size, type and position.
9. Duty Cycle
Tell us whether the motor operates:
- Continuously
- Intermittently
- Under shock loads
- At high starting torque
- At very low speed
- At high speed
10. Application
Always provide the machine and function for which the motor is being used.
Tips for Buying a Hydraulic Motor
Tip 1: Use the Complete Part Number
The complete part number is one of the most useful pieces of information when identifying a replacement.
Tip 2: Send a Photograph
A clear photograph of the hydraulic motor nameplate can significantly assist with identification.
Tip 3: Do Not Match Only by Appearance
Two hydraulic motors may look similar but have different displacement, pressure ratings, shaft dimensions or internal configurations.
Tip 4: Check the Hydraulic Circuit
The motor must be compatible with the pump, valves, hoses, controls and hydraulic circuit.
Tip 5: Check Case Drain Requirements
Some piston motors require specific case-drain arrangements and allowable case pressure.
Tip 6: Check Pressure and Flow
Do not select a motor solely based on physical size. Verify the hydraulic operating parameters.
Tip 7: Check the Application
A motor designed for a conveyor or sweeper may not be suitable for a heavy-duty mining drive.
Tip 8: Consider OEM and Aftermarket Options
Depending on availability and budget, Nkokhi Group can investigate OEM, aftermarket and equivalent replacement options.
Hydraulic Motor Problems & Troubleshooting
Common hydraulic motor symptoms include:
Hydraulic Motor Not Turning
Possible causes include:
- Insufficient hydraulic flow
- Low system pressure
- Incorrect valve operation
- Mechanical seizure
- Damaged motor
- Blocked hydraulic line
- Incorrect installation
Hydraulic Motor Turning Slowly
Possible causes include:
- Insufficient flow
- Internal leakage
- Worn rotating group
- Excessive hydraulic oil temperature
- Incorrect motor displacement
- Hydraulic pump problems
Hydraulic Motor Losing Torque
Possible causes include:
- Low system pressure
- Internal wear
- Excessive internal leakage
- Incorrect displacement
- Hydraulic contamination
- Pump performance problems
Hydraulic Motor Overheating
Possible causes include:
- Excessive leakage
- Excessive pressure
- Restricted return line
- Incorrect case-drain configuration
- Contaminated hydraulic oil
- Insufficient cooling
A hydraulic system should be diagnosed before replacing the motor to avoid replacing a component when the underlying problem is elsewhere.
Hydraulic Motors for Mining Equipment
Mining equipment requires hydraulic components capable of operating under demanding conditions.
Nkokhi Group can source hydraulic motors for:
- Mining excavators
- Drill rigs
- Underground mining equipment
- Conveyors
- Crushers
- Feeders
- Winches
- Material-handling systems
- Heavy-duty mobile equipment
For high-torque, low-speed applications, radial piston and other specialised motor designs may be appropriate depending on the required operating conditions.
Hydraulic Motors for Industrial Applications
Hydraulic motors are used across many industrial sectors, including:
- Manufacturing
- Steel processing
- Mining
- Cement
- Recycling
- Material handling
- Food processing
- Marine
- Forestry
- Agriculture
- Construction
- Bulk materials handling
Applications include:
- Conveyors
- Winches
- Mixers
- Fans
- Rollers
- Drilling systems
- Cranes
- Rotary drives
- Machine tools
- Industrial automation
Why Choose Nkokhi Group?
Nkokhi Group provides hydraulic component sourcing solutions for customers across South Africa and the broader African market.
Our hydraulic motor service includes:
✔ Hydraulic motor identification
✔ Replacement motor sourcing
✔ OEM motor sourcing
✔ Aftermarket alternatives
✔ Hydraulic motor model identification
✔ Part-number cross-reference
✔ Technical specification matching
✔ Earthmoving equipment applications
✔ Mining equipment applications
✔ Industrial hydraulic applications
✔ Assistance with imported hydraulic components
We work with international manufacturers and hydraulic component suppliers to source solutions according to the customer’s machine, application and technical requirements.
How to Order a Hydraulic Motor
To obtain a quotation, send Nkokhi Group as much of the following information as possible:
1. Hydraulic motor manufacturer
2. Complete part number
3. Motor model
4. Machine manufacturer
5. Machine model
6. Machine serial number
7. Motor nameplate photograph
8. Required quantity
9. Application
10. Delivery location
For difficult-to-identify motors, provide photographs of the nameplate, mounting flange, shaft and hydraulic ports.
Frequently Asked Questions
What is a hydraulic motor?
A hydraulic motor converts pressurised hydraulic fluid into rotary mechanical power. The motor uses hydraulic pressure and flow to generate shaft rotation and torque.
What are the main types of hydraulic motors?
The main types include gear motors, orbital/gerotor motors, vane motors, axial piston motors, bent-axis piston motors and radial piston motors.
What is an orbital hydraulic motor?
An orbital hydraulic motor is a low-speed, high-torque motor using an orbital/gerotor-type operating principle. It is commonly used in mobile equipment, conveyors, sweepers, augers and other applications.
What is a hydraulic piston motor?
A piston motor uses pistons to convert hydraulic pressure into rotary movement. Axial piston and radial piston motors are commonly used for demanding hydraulic applications.
What is the difference between an axial and radial piston motor?
Axial piston motors arrange pistons parallel to the motor’s axis of rotation, while radial piston motors arrange pistons around the central axis. Radial piston motors are particularly suited to high-torque, low-speed applications.
Can Nkokhi Group supply replacement hydraulic motors?
Yes. Nkokhi Group can source replacement hydraulic motors according to the original part number, machine model, motor specifications and application.
Can you supply hydraulic motors for excavators?
Yes. We can source hydraulic motors for excavators, including travel motors, swing motors and other hydraulic drive applications, subject to identification and availability.
Can you supply hydraulic motors for mining equipment?
Yes. Nkokhi Group can source hydraulic motors for mining, quarrying, material handling and heavy industrial applications.
Can you identify a hydraulic motor from a photograph?
Yes. A clear photograph of the motor nameplate, part number and physical mounting configuration can assist with identification.
Do you supply OEM hydraulic motors?
OEM availability depends on the manufacturer and model. We can investigate OEM and suitable replacement or aftermarket alternatives.
How do I select the correct hydraulic motor?
Start with the motor part number and application, then verify displacement, pressure, flow, speed, torque, shaft, mounting, ports, rotation and duty cycle.
Where can I buy hydraulic motors in South Africa?
Nkokhi Group supplies and sources hydraulic motors for customers in South Africa. Contact us with your motor part number, machine model or nameplate photograph for a quotation.
Request a Hydraulic Motor Quote
Looking for a hydraulic motor for sale in South Africa?
Send Nkokhi Group your part number, motor model, machine model, serial number or nameplate photograph.
We can assist with sourcing hydraulic motors, orbital motors, piston motors, radial piston motors, axial piston motors, gear motors, wheel motors and replacement hydraulic motors for construction, mining, earthmoving and industrial equipment.
Nkokhi Group (Pty) Ltd
South Africa
Request your hydraulic motor quotation today.
