Pulverized Coal Pipe Knee Joint Assembly for Sale in South Africa | Nkokhi Group
Part Number 0615097 – Eskom Matimba Specification | Industrial Power Station Spare Parts
Nkokhi Group supplies industrial spare parts, engineered components, and equipment for power generation, mining, heavy industry, and industrial maintenance applications across South Africa. We assist procurement departments, maintenance contractors, engineering companies, and industrial operators with sourcing specialised components according to specified part numbers, technical drawings, material grades, and application requirements.
We specialise in sourcing pulverized coal pipe knee joint assemblies, including the 0615097 ASSY: KNEE JOINT for pulverized coal pipes, manufactured to the supplied Eskom Matimba specification and engineering drawing requirements.
Whether you require a new knee joint assembly, replacement components, or assistance sourcing a suitable manufacturer, Nkokhi Group can assist with your procurement requirements.
Product: ASSY: Knee Joint – Pulverized Coal Pipes
Part Number: 0615097
Application: Pulverized Coal Conveying Systems
Specification: Eskom Matimba Specification
Drawing Number: 20.58/56003 Rev 0
Supply: Subject to technical verification, manufacturer confirmation, and availability
Market: South Africa
Contact Nkokhi Group for a quotation on part number 0615097 and other specialised industrial power station spare parts.
1. Pulverized Coal Pipe Knee Joint Assembly – Product Overview
A pulverized coal pipe knee joint is an engineered connection component used in coal-fired power generation systems to accommodate directional changes in pulverized coal conveying pipework.
These assemblies operate in demanding industrial environments where abrasive coal particles, elevated temperatures, mechanical stresses, and continuous operation can contribute to component wear.
The correct knee joint assembly must meet the specified dimensional, material, sealing, and mechanical requirements to support reliable operation and maintain the integrity of the coal conveying system.
The 0615097 knee joint assembly, specified for Eskom Matimba, is identified by the supplied engineering details and drawing number 20.58/56003 Rev 0.
Nkokhi Group can assist with sourcing this component using the original part number, technical specification, and drawing reference to help ensure that the quoted product matches the required application.
2. Technical Specifications – Part Number 0615097
The following specifications are based on the supplied Eskom Matimba product description.
| Specification | Details |
|---|---|
| Part Number | 0615097 |
| Component Description | ASSY: Knee Joint |
| Application | Pulverized Coal Pipes |
| Installation | Coal-fired power generation systems |
| Inside Diameter (ID) | 610 mm |
| Outside Diameter (OD) | 729 mm |
| Material | CR High Cast, as specified |
| Material Specification | 22%–28% BS4844, as supplied |
| Drawing Number | 20.58/56003 |
| Drawing Revision | Revision 0 |
| Assembly Configuration | Male component, female component, ring, fasteners, plug, and seal |
| Seal Type | Flexible graphite with inserted Inconel |
| Seal Dimensions | 10 × 10 mm |
| Bolt Specification | M14 × 75 mm |
| Washer Specification | M14 |
| Plug Specification | M10 |
| Original Equipment Application | Eskom Matimba |
| Supply Condition | New manufacture or replacement supply, subject to confirmation |
Important technical note: The material description “CR High Cast” and the specification “22%–28% BS4844” are reproduced from the supplied requirements. The exact material designation, applicable standard, and interpretation of the percentage range should be confirmed against the original engineering drawing and approved material documentation before manufacture.
3. Assembly Components
The specified knee joint assembly comprises the following items:
Item 1 – Male Component
The male section forms part of the mechanical connection between the associated pipework components. Its dimensions, material composition, and interface must match the approved engineering drawing.
Item 2 – Female Component
The female section mates with the corresponding male component to form the required connection. Correct dimensional compatibility is essential for assembly integrity and sealing performance.
Item 3 – Ring
The ring forms part of the specified assembly configuration. Its exact profile, dimensions, and material should be verified against drawing 20.58/56003 Rev 0.
Item 4 – M14 × 75 mm Bolts
The specified fasteners secure the relevant assembly components. Bolt grade, finish, and tightening requirements must be confirmed against the original specification.
Item 5 – M14 Washers
The washers are included as part of the specified fastening arrangement. The required washer type and material should be confirmed before procurement.
Item 6 – M10 Plug
The M10 plug is included in the original assembly specification. Its location, thread form, and sealing arrangement must be verified against the engineering drawing.
Item 7 – Flexible Graphite Seal with Inconel Insert
The specified seal measures 10 × 10 mm and incorporates an Inconel insert within flexible graphite, with a graphite finish as described in the supplied specification.
The replacement seal must be compatible with the assembly’s operating temperature, pressure conditions, coal dust exposure, and mechanical requirements.
4. Pulverized Coal Pipe Knee Joints for Eskom Power Stations
Coal-fired power stations depend on reliable fuel handling and pulverized coal conveying equipment to support boiler operation.
Specialised pipe connections and knee joint assemblies must be manufactured or sourced to the correct engineering requirements to maintain compatibility with the existing installation.
Nkokhi Group assists industrial procurement teams with sourcing components for applications such as:
- Pulverized coal conveying pipework.
- Coal-fired power station maintenance.
- Industrial boiler fuel supply systems.
- Power station mechanical maintenance.
- Replacement of worn or damaged pipe joints.
- Planned plant shutdowns and maintenance projects.
- Industrial piping and engineered component replacement.
- Specialised assemblies manufactured to approved engineering drawings.
When sourcing components for Eskom facilities or other power generation installations, it is important to verify the original part number, drawing revision, material specification, and any site-specific procurement requirements.
5. New, Replacement and Custom-Manufactured Knee Joint Assemblies
Nkokhi Group can assist with enquiries for new and replacement pulverized coal pipe knee joint assemblies.
Depending on technical approval, manufacturer capability, and availability, sourcing options may include:
New knee joint assemblies: New components manufactured or supplied to the approved technical specification.
Replacement assemblies: Components intended to replace worn, damaged, or obsolete installations while retaining the required design and interface compatibility.
Drawing-based manufacture: Assistance sourcing a suitable engineering manufacturer capable of reviewing drawing 20.58/56003 Rev 0 and confirming manufacturing feasibility.
Component-level sourcing: Enquiries for individual assembly items, including male and female sections, rings, fasteners, plugs, and specified sealing materials.
Shutdown and maintenance procurement: Assistance with quotations for planned maintenance projects, subject to supplier lead times and material availability.
All replacement and custom-manufactured components should undergo the required engineering review and approval before installation.
6. Manufacturers and Suppliers of Industrial Knee Joint Assemblies
The manufacture of specialised pulverized coal pipe knee joints may require expertise in industrial castings, wear-resistant materials, precision machining, engineered pipe connections, and high-temperature sealing systems.
When evaluating potential manufacturers, Nkokhi Group recommends assessing the following supplier categories.
Industrial Casting Manufacturers
Suitable casting manufacturers may be able to produce the specified components using an approved material grade and the required casting process. Their capability should be verified against the original drawing and material requirements.
Power Station Component Manufacturers
Specialist suppliers serving coal-fired power stations may have experience with pulverized coal conveying systems, boiler-related pipework, and engineered replacement components.
Heavy Engineering and Machining Companies
Engineering manufacturers with suitable machining facilities may be able to produce or finish the male and female sections, rings, and associated components to the approved dimensional requirements.
Industrial Sealing Manufacturers
Specialist sealing suppliers can assist with flexible graphite seals incorporating Inconel inserts, provided the proposed product meets the specified dimensions and service requirements.
OEM and Approved Replacement-Part Suppliers
Where available, the original equipment manufacturer or an approved replacement-part supplier should be consulted to establish the correct component configuration and applicable engineering requirements.
Manufacturer verification: No specific manufacturer is confirmed here as the original producer of part number 0615097. Prospective manufacturers should be assessed for their ability to meet the supplied Eskom Matimba specification rather than selected on product description alone.
7. How to Source Pulverized Coal Pipe Knee Joint Assemblies in South Africa
Finding a specialised power station component can be challenging when it is not available through ordinary industrial supply channels.
Nkokhi Group helps streamline the procurement process by using the available technical information to identify suitable suppliers and obtain quotations.
To request a quotation, provide:
- Part number: 0615097.
- Description: ASSY: Knee Joint – Pulverized Coal Pipes.
- Application: Eskom Matimba.
- Drawing number: 20.58/56003 Rev 0.
- Required quantity.
- Required delivery date.
- Delivery location in South Africa.
- Any applicable Eskom vendor, quality, or documentation requirements.
Where available, attach the original drawing, photographs, material certificates, and previous purchase documentation.
This information helps suppliers evaluate the requirements accurately and reduces the risk of receiving an incompatible component.
8. Important Purchasing Tips
Before purchasing a pulverized coal pipe knee joint assembly, consider the following recommendations.
Verify the Part Number
Confirm that the required component is part number 0615097 and that the application matches the intended installation.
Confirm the Engineering Drawing
Request confirmation that the proposed assembly is compatible with drawing 20.58/56003 Rev 0. Check whether a newer approved revision exists.
Check Dimensions
Verify the specified 610 mm inside diameter and 729 mm outside diameter against the original drawing and existing installation.
Confirm the Material Grade
Do not rely solely on a general description such as high-chromium casting. Obtain the exact approved material designation and supporting material documentation.
Verify the BS4844 Reference
Confirm the intended meaning and applicability of the supplied “22%–28% BS4844” specification with the responsible engineer before ordering.
Inspect the Sealing Arrangement
Ensure that the flexible graphite seal with Inconel insert matches the required 10 × 10 mm specification and the application’s operating conditions.
Confirm Fastener Requirements
Check bolt length, thread, material grade, washer type, and plug configuration before accepting the assembly.
Request Quality Documentation
Depending on the purchase specification, request material certificates, dimensional inspection reports, manufacturing records, and other required quality documentation.
Plan for Lead Times
Specialised castings and drawing-based components may require additional manufacturing and inspection time. Confirm the delivery schedule before committing to a plant shutdown or maintenance programme.
Obtain Engineering Approval
Ensure that any proposed alternative or locally manufactured component receives the necessary technical approval before installation.
9. Why Contact Nkokhi Group?
Nkokhi Group (Pty) Ltd supports industrial procurement requirements by assisting customers with specialised spare parts, engineered components, and hard-to-source equipment.
Our sourcing approach focuses on the information required to identify and quote the correct product.
Customers can approach Nkokhi Group for:
- Specialised industrial spare parts.
- Power station component sourcing.
- Part-number-based procurement.
- Drawing-based manufacturing enquiries.
- New and replacement component quotations.
- Assistance sourcing industrial sealing products.
- Supplier and manufacturer enquiries.
- Delivery arrangements within South Africa.
- Support with technical information required for quotations.
Our objective is to help customers identify suitable supply options while maintaining attention to the specified part number, dimensions, material requirements, and engineering documentation.
Looking for part number 0615097? Contact Nkokhi Group with your required quantity and delivery location for a quotation on the Eskom Matimba pulverized coal pipe knee joint assembly.
10. Frequently Asked Questions
What is part number 0615097?
Part number 0615097 refers to an assembly described as “ASSY: KNEE JOINT; PULVERIZED COAL PIPES” in the supplied Eskom Matimba specification.
What is a pulverized coal pipe knee joint?
It is a specialised pipework connection component used in pulverized coal conveying systems. The exact configuration and function of the specified assembly must be confirmed against its engineering drawing.
What are the dimensions of the 0615097 knee joint assembly?
The supplied specification lists an inside diameter of 610 mm and an outside diameter of 729 mm. These dimensions should be checked against drawing 20.58/56003 Rev 0 before manufacture or purchase.
Which material is specified for this assembly?
The supplied description identifies the material as “CR High Cast” and references “22%–28% BS4844.” The exact material designation and applicable standard require confirmation from the original engineering documentation.
Which components are included in the assembly?
The specified assembly comprises a male component, female component, ring, M14 × 75 mm bolts, M14 washers, an M10 plug, and a 10 × 10 mm flexible graphite seal with an inserted Inconel component.
Can Nkokhi Group supply the Eskom Matimba knee joint?
Nkokhi Group can assist with a sourcing and quotation enquiry for part number 0615097. Final supply is subject to manufacturer confirmation, technical compliance, availability, and applicable procurement requirements.
Can the knee joint be manufactured from a drawing?
Potentially, yes. A suitably qualified engineering manufacturer can assess the supplied drawing and confirm whether the component can be manufactured to the required material, dimensional, and quality specifications. Engineering approval may be required before production.
Can I purchase only the seal or fasteners?
Individual components may be sourced separately, subject to supplier availability and confirmation of their specifications. Provide the relevant item number and technical details when requesting a quotation.
What information is required to obtain a quotation?
Provide the part number, description, quantity, drawing reference, delivery location, and required delivery date. Additional technical documentation may be necessary to confirm compliance.
How long does delivery take?
Lead time depends on stock availability, material sourcing, manufacturing requirements, inspection, and delivery arrangements. Request a confirmed lead time when obtaining your quotation.
Does Nkokhi Group supply other industrial power station spare parts?
Nkokhi Group can assist with enquiries for a range of industrial and specialised spare parts, subject to product availability, supplier capability, and technical requirements.
11. Request a Quotation – Part Number 0615097
Are you looking for a pulverized coal pipe knee joint assembly in South Africa?
Contact Nkokhi Group (Pty) Ltd for assistance sourcing the Eskom Matimba knee joint assembly, part number 0615097.
Product: ASSY: Knee Joint – Pulverized Coal Pipes
Part Number: 0615097
Drawing: 20.58/56003 Rev 0
Dimensions: ID 610 mm × OD 729 mm
Application: Eskom Matimba pulverized coal pipework
When submitting your enquiry, include the quantity required, delivery location, and any available technical drawings or procurement documentation.
Nkokhi Group will assist with evaluating suitable sourcing options and obtaining a quotation, subject to supplier and manufacturer confirmation.
Nkokhi Group (Pty) Ltd – Industrial Spare Parts and Engineering Component Sourcing in South Africa.
